Additional Features

• Flat Back: Allows valve to be mounted flush against cross brace for an easy and solid installation
• Flush plug: This allows the valve body to be tested and flushed without the presence of the valve cartridge. Can be tested using a flush plug with air (200 psi) or water (300 psi).
• Stainless Steel Retaining Ring with Flats: Secures test cap/cartridge in place and eliminates the need for screws. Flats make it simple to loosen the ring for quick, easy insertion/removal of flush plug/cartridge.
• Back-to-Back Capability: Hot and cold can be reversed quickly and easily. Exclusive Plaster Guard: The plaster guard is designed to protect the valve and act as a guide during installation. It can serve as mounting support for thin-wall installations.
• Wide Rough-in Range: From 1-3/4" to 2-3/4" from the finished wall to the back of the valve
• Cartridge ships with trim
• Meets or Exceeds ASSE 1016/ASME A112.18.1016/CSA B125.16
